Abstract
The aim of the paper is to present the application of MSC Adams/View for kinematic analysis of a press mechanism. The press mechanism is simulated in MSC Adams/View software. MSC Adams and its modules Adams/View work with this module and its basic operation is dedicated to the solution of kinematics by means of numerical methods. Press mechanism works on the principle of converting rotational motion of a crank to translational motion of a slider block. This paper deals with model press mechanism in Adams/View, simulation running, plotting of the mechanisms points trajectory and kinematic parameters of mechanism members. The computer program shows displacement, velocity and acceleration, and angular velocity and angular acceleration. The paper presents the results with graphic display of parameters such as displacement, velocity, and acceleration.
At a glance: Figures
MSC Software is a global leader in helping product manufacturers to advance their engineering methods with simulation software and services. SimAcademy Webinar: Contact Modeling in Adams –Contact Parameters & Integrator Settings for Rigid and Flex Body Contact. Msc adams front suspension template 2014. The Computer-Aided Design ('CAD') files and all associated content posted to this website are created, uploaded, managed and owned by third party users. Adams/View Command Language help - Adams 2014: 6,274: Nov 18, 2014: DOC10648. DOC9398 - Adams/Car help - MSC Adams 2010: DOC10066 - Adams 2012.1.1 Release Guide.
Keywords: MSC Adams/View, press mechanism, simulation, kinematic analysis
American Journal of Mechanical Engineering, 2014 2 (7), pp 312-315.
DOI: 10.12691/ajme-2-7-30
Received October 6, 2014; Revised October 27, 2014; Accepted November 18, 2014
Copyright © 2013 Science and Education Publishing. All Rights Reserved.Cite this article:
- Hroncová, Darina, et al. 'Kinematic Analysis of the Press Mechanism Using MSC Adams.' American Journal of Mechanical Engineering 2.7 (2014): 312-315.
- Hroncová, D. , Frankovský, P. , Virgala, I. , & Delyová, I. (2014). Kinematic Analysis of the Press Mechanism Using MSC Adams. American Journal of Mechanical Engineering, 2(7), 312-315.
- Hroncová, Darina, Peter Frankovský, Ivan Virgala, and Ingrid Delyová. 'Kinematic Analysis of the Press Mechanism Using MSC Adams.' American Journal of Mechanical Engineering 2, no. 7 (2014): 312-315.
| Import into BibTeX | Import into EndNote | Import into RefMan | Import into RefWorks |
1. Introduction
Current software simulation technologies make it easy to design mechanisms with complex kinematic structure. Computer programs significantly reduce time and facilitate the work when solving practical mechanisms. Applying software simulation model, we create a mechanism which corresponds to a real machine. With computer models we can analyze in detail the solution of real objects in practice. Using computer simulations, we can expect desired behavior of the model under loads that may occur because the elimination of problems in the real system is financially much more demanding and, of course, time-consuming.
Kinematic analysis is the process of measurement of kinematic quantities which is used to describe motion. In engineering, for instance, kinematic analysis may be used to find the range of movement for a given mechanism [3]. Kinematic synthesis designs a mechanism for a desired range of motion [4].
In this paper, we deal with kinematic analysis of the press mechanism in Figure 1 which is driven by the crank which rotates with constant angular velocity.
This work deals with the simulation program MSC Adams which was used to simulate the movement of the pump mechanism. The result is presented in a graphical representation of the movement of individual elements as well as respective members of the mechanism [1]. Displacement, velocity and acceleration of key points are plotted and the trajectory of chosen points is also plotted [2].
2. MSC Adams Main Characteristic
Computer software MSC Adams (Automatic Dynamic Analysis of Mechanical Systems) is one of the most widely used multi-function computing software. The program allows us to create dynamic, kinematic and static analysis of the proposed mechanical systems and helps us to optimize and improve their properties. It helps in simulations of mechanical systems consisting of rigid and flexible bodies connected by different types of kinematic links and joints [2, 6, 7].
3. Model of the Press Mechanism
The press mechanism works on the principle of converting rotational motion of the crank 2 to translational motion of the slider block 6. Driving link OA has a counterclockwise angular velocity of the 6 rad.s-1. The task is to calculate the absolute speed of the member 6, the size of angular velocity of the member 3, angular velocity and angular accelerations of the member 4 and kinematic parameters of other press machine members [8].
The aim of the computer simulation by MSC Adams/View is to build the model of the press mechanism. Our goal is to determine kinematic variables of rotational motion, translational motion and general plane motion of the members.
A generalized diagram of the press mechanism is shown in Figure 1.
Member OA of the mechanism is formed by the crank and in ADAMS/View program it is a rigid body with geometry named Link. Parameters of the body 2 are as follows: length 0,15 m, width 0,04 m, depth 0,04 m.
Member AB of the mechanism is formed by a connecting rod and in the program it is a rigid body with geometry named Link. Parameters of the body 3 are as follows: length 0,84 m, width 0,04 m, depth 0,04 m.
Member BC of the mechanism is formed by the crank and in the program it is a rigid body with geometry named Link. Parameters of the body 4 are as follows: length 0,5 m, width 0,04 m, depth 0,04 m.
Member BD of the mechanism is formed by the connecting rod and in the program it is a rigid body with geometry named Link. Parameters of the body 5 are as follows: length 0,7 m, width 0,04 m, depth 0,04 m.
The member 6 of the mechanism is formed by a piston and in the program it is a rigid body with geometry nemed Box. Parameters of the body 6 are as follows: length 0.1 m, width 0,16 m, depth 0,1 m.
Next parameters of the mechanism are angle φ=45°, a=1,05 m and b=0,5 m. The mechanism contains rotational joint, translational joint and fixed joint as shown in Figure 2b. Motion is in joint 1 in point O with angular velocity 6 rad. sec-1.
Simulation parameters are: End Time 10 second and Steps 200.
3.1. Compilation of the Model in MSC AdamsUsing basic building blocks, we compile a model of the press mechanism in MSC Adams/View (Figure 2). The model will be projected in several steps as described in the following sections [2].
Trajectory of the mass center is plotted by function Trace Marker in Figure 3. It shows trajectory of point members 3, 5 and 6.
To determine the values of the parameters it is necessary to define several properties in measurement windows [1]. After opening the dialog box for the determined angle, velocity and acceleration, is necessary to define important parameters [3, 4]. The time course angle of rotation member 2 is shown in Figure 5.
Msc Adams Training
Angular velocity of the PART_2 is 343,77 rad.sec-1 (Figure 7).
Figure 8 shows an example of measurement windows with kinematics parameter of the point D member 6.
Dependence of kinematic variable of velocity of the member 6 from time is shown in Figure 10.
The following picture (Figure 11) demonstrates acceleration of point D in the member 6 in graphical form.
Dependence of kinematic variables of angular velocity of the member 3 from time is shown in Figure 12.
Dependence of kinematic variables of angular velocity of the member 4 from time are shown in Figure 13.
Dependence of kinematic variables of angular acceleration of the member 4 from time is shown in Figure 14.
The diagram in Figure 15 shows the dependence of angular velocity from time of the member 5.
The diagram in Figure 16 shows the dependence of angular acceleration from time of the member 5.
Msc Adams 2014 Pro
Creating animation file of press mechanism is shown in Figure 17.
4. Summary
Great benefit of the study is the familiarity with the issues and new opportunities to learn how to work with the simulation program MSC ADAMS/View, which is used for modeling systems of more degrees of freedom, their static, kinematics and dynamic analysis [3-4][3]. The result of the simulation enables a graphical and numerical form [2]. Diagrams of kinematic variables were created in Adams/Postprocessor, one of the modules of the program MSC Adams/View. The program allows us to create a video file in *. avi format as shown in Figure 17.
In such form, the article may serve educational purposes to find out more about simulation in software MSC ADAMS/View.
